Skyjack SJ85 AJ Service Manual

55
SJ85 AJ 229044ADA
Hydraulic Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
CB10 141399 VALVE, Counterbalance - platform rotate
CB11 141399 VALVE, Counterbalance - platform rotate
CB12 212872 VALVE, Counterbalance - axle lock
CB13 212872 VALVE, Counterbalance - axle lock
CB14 212624 VALVE, Counterbalance - lift cylinder
CB15 212663 VALVE, Counterbalance - riser
CB16 212663 VALVE, Counterbalance - riser
CV1 159842 VALVE, Check - auxiliary pump
CV2 171389 VALVE, Check - main inlet
CV3 199471 VALVE, Check - main LS
CV4 199471 VALVE, Check - main LS
CV5 199471 VALVE, Check - main LS
CV6 199471 VALVE, Check - main LS
CV7 212549 VALVE, Check - jib/platform return
CV8 197770 VALVE, Check - leverl override
CV9 197770 VALVE, Check - level override
CV10 171411 VALVE, Check - steer load sense
CV11 171412 VALVE, Check - swing drive load sense
CV12 171412 VALVE, Check - riser shuttle LS
CV13 171412 VALVE, Check - lift load sense
CV14 171412 VALVE, Check - extend load sense
CV15 171411 VALVE, Check - platform level LS
CV16 159842 VALVE, Check - boom lift suction
CV17 159842 VALVE, Check - riser down suction
CV18 171412 VALVE, Check - platform/jib load sense
CV19 N/A VALVE, Check - generator 3.5 kW
CV20 159814 VALVE, Check - generator 12 kW manifold LS
CV21 171410 VALVE, Check - generator 12 kW manifold
CV22 N/A VALVE, Check - generator 12 kW
CV23 159814 VALVE, Check - generator 3.5 kW LS
CV24 159814 VALVE, Check - generator 7.5 kW LS
CV25 171410 VALVE, Check - generator 7.5 kW LS
CV26 171434 VALVE, Check - generator 7.5 kW LS
DSV1 166063 VALVE, Compensator - swing
DSV2 212550 VALVE, Compensator - boom extend
DSV3 212551 VALVE, Compensator - boom lift
DSV4 212550 VALVE, Compensator - riser
EPU 198009 PUMP, Emergency
F1 161932 FILTER, High pressure
F2 161933 FILTER, Return
FR1 166058 VALVE, Flow regulator
M1A 171944 MOTOR, Axle drive
M1B 171944 MOTOR, Axle drive
M2 170930 MOTOR, Swing drive
M3 171419 MOTOR, Generator 3.5 kW
M4 171438 MOTOR, Generator 12 kW
MB1 198103 MANIFOLD, Main
