Skyjack SJ85 AJ Service Manual

56
SJ85 AJ229044ADA
Section 3 – System Component Identification and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
MB2 198368 MANIFOLD, Brake
MB3 198369 MANIFOLD, Jib
MB5 168618 MANIFOLD, Generator - 3.5 kW
MB6 171437 MANIFOLD, Generator - 12 kW
OR1 212559 ORIFICE, Main manifold (0.090")
OR2 199475 ORIFICE, Main manifold (0.055")
OR3 171416 ORIFICE, Main manifold (0.020")
OR4 171416 ORIFICE, Main manifold (0.020")
OR5 171416 ORIFICE, Main manifold (0.020")
OR6 171416 ORIFICE, Main manifold (0.020")
OR9 171420 ORIFICE, Bleed off (0.073")
P1A 154119 PUMP, Charge
OR10 171450 VALVE, Flow regulator
OR11 171450 VALVE, Flow regulator
OR12 171450 VALVE, Flow regulator
P1A 169006 PUMP, Hydrostatic
P2 165101 PUMP, System
PR1 211704 VALVE, Pressure reducing - 400 psi
PR2 212548 VALVE, Pressure reducing - 80 psi
QD1 122420 FITTING, Quick disconnect
RA1 144710 ACTUATPR, Platform with jib
RA2 167073 ACTUATOR, Swing
RV1 188759 VALVE, Relief - main manifold
RV2 171428 VALVE, Relief - swing drive
RV3 166047 VALVE, Relief - platform level
RV4 212557 VALVE, Relief - Riser
RV5 216236 VALVE, Relief - Boom lift
RV6 212556 VALVE, Relief - Boom extend
RV7 N/A VALVE, Relief - Charge
RV8 N/A VALVE, Relief - EPU
SV1 141414 VALVE, Shuttle - brake manifold
SV2 166054 VALVE, Shuttle - brake manifold
SV3 166054 VALVE, Shuttle - riser
SV4 141414 VALVE, Shuttle - boom lift
SV5 N/A VALVE, Shuttle - swing drive brake
V1 113752 VALVE, Brake release override
V2 223204 VALVE, Pilot operated
V3 159831 VALVE, Brake hand pump
V4 212553 VALVE, Pilot operated
V5 230202 VALVE, Pilot operated
V6 212552 VALVE, Pilot operated
V8 166053 VALVE, Loop flush
