Section 2 – Maintenance Tables and Diagrams Standard Hose Numbering System
Hose
Prefix
Hose End Fitting Hose End Fitting
S.A.E. Hose
Specification
H15 REUSABLE FEMALE, 37° JIC, SWIVEL REUSABLE FEMALE, 37° JIC, SWIVEL 300 PSI
H16 NO FITTING NO FITTING 100R4
H17 NO FITTING NO FITTING 300 PSI
H18 REUSABLE, FEMALE, 37° JIC, SWIVEL NO FITTING 300 PSI
H19 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R13
H20 FEMALE, SHORT 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R4
H21 FEMALE, SHORT 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R2AT
H22 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R2AT
H23 FEMALE, LONG 37° JIC, SWIVEL LONG 90°, FEMALE, 37° JIC, SWIVEL 100R2AT
H24 FEMALE, SHORT 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R13
H25 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
H30 MEDIUM 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H31 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H32 SHORT 45°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H33 MEDIUM 45°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H34 SHORT 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H35 MEDIUM 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H36 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H37 SHORT 45°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
H38 SHORT 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
H39 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
H40 SHORT 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R16
H43 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R16
H51 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H52 SHORT 45°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H53 MEDIUM 45°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H54 SHORT 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H55 MEDIUM 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H56 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H57 SHORT 45°, FEMALE, SAE ORFS, SWIVEL FEMALE, SAE ORFS, SWIVEL 100R13
H58 FEMALE, SAE ORFS, SWIVEL FEMALE, SAE ORFS, SWIVEL 100R13
H59 MEDIUM 90°, FEMALE, SAE ORFS, SWIVEL FEMALE, SAE ORFS, SWIVEL 100R13
H60 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H61 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R16
H62 SHORT 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R16
H63 MEDIUM 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R16
H64 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R16
H65 MEDIUM 67°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R12
H66 FEMALE, 37° JIC, SWIVEL NO FITTING 100R4
H67 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R19
H68 SHORT 45°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R19
H69 MEDIUM 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R19
H70 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R19
H71 LONG 90°, FEMALE, SAE ORFS, SWIVEL FEMALE, SAE ORFS, SWIVEL 100R15
