LD301 – Operation and Maintenance Instruction Manual
6.4
Performance Specifications
6 mmH
2
O per 20 ºC for 4" and DN100
17 mmH
2
O per 20 ºC for 3" and DN80
Consult Smar for other flange dimensions and fill fluid.
Static Pressure
Effect
Zero error:
For ranges 2, 3, 4 and 5: ± 0.033% of URL per 7MPa (1000 psi)
For range 1: ± 0.05% of URL per 1.7 MPa (250 psi)
For range 0: ± 0.1% of URL per 0.5 MPa (5 bar)
For Level model: ± 0.1% of URL per 3.5 MPa (500 psi)
The zero error is a systematic error that can be eliminated by calibrating at the operating static pressure.
Span error:
For ranges 2, 3, 4, 5 and 6: correctable to ± 0.2% of reading per 7MPa (1000 psi)
For range 1 and level transmitters: correctable to ± 0.2% of reading per 3.5 MPa (500 psi)
For range 0: correctable to ± 0.2% of reading per 0.5 MPa (5 bar) (70 psi)
Power Supply
Effect
± 0.005% of calibrated span per volt
Mounting Position
Effect
Zero shift of up to 250 Pa (1 inH2O) which can be calibrated out.
No span effect.
Electromagnetic
Interference Effect
Approved according to IEC61326-1:2006, IEC61326-2-3:2006, IEC61000-6-4:2006, IEC61000-6-2:2005.
Physical Specifications
Electrical
Connection
1/2 - 14 NPT
3/4 - 14 NPT with 316 SST adapter for 1/2 - 14 NPT)
3/4 - 14 BSP with 316 SST adapter for 1/2 - 14 NPT)
1/2 - 14 BSP with 316 SST adapter for 1/2 - 14 NPT)
M20 X 1.5
PG 13.5 DIN
Note: Explosion Proof approvals do not apply to
adapter, only to transmitter.
Process
Connection
1/4 - 18 NPT or 1/2 -14 NPT (with adapter)
For level models or other options, see the Ordering Code.
Wetted Parts
Isolating Diaphragms:
316L SST, Hastelloy C276, Monel 400 or Tantalum
Drain/Vent Valves and Plug:
316 SST, Hastelloy C276 or Monel 400
Flanges:
Plated Carbon Steel, 316 SST-CF8M (ASTM - A351), Hastelloy C276 - CW-12MW, (ASTM - A494) or
Monel 400
Wetted O-Rings (For Flanges and Adapters):
Buna N, Viton™ PTFE or Ethylene-Propylene.
The LD301 is available in NACE MR-01-75/ISO 15156 compliant materials.
Nonwetted Parts
Electronic Housing:
Injected aluminum with polyester painting, epoxy painting or 316 SST - CF8M (ASTM - A351) housing.
Complies with NEMA 4X/6P, IP66 or IP66W*, IP68 or IP68W*.
*The IP66/68W sealing test (immersion) was performed at 1 bar for 24 hours. For any other situation, please consult
Smar. IP66/68W tested for 200h to according NBR 8094 / ASTM B 117 standard.
Blank Flange:
When flange adapter and Drain/Vent material is carbon steel, blank flange is in carbon steel, otherwise
blank flange is in 316 SST - CF8M (ASTM - A351)
Level Flange (LD301L):
316 L SST, 304 SST, Hastelloy C276 and Plated Carbon Steel.
Fill Fluid:
Silicone, Inert , Krytox, Halocarbon 4.2 or Fomblim oils
Cover O-Rings:
Buna N
Mounting Bracket:
Plated carbon steel or 316 SST
Accessories (bolts, nuts, washers and U-clamps) in carbon steel or 316 SST
