SMART MX Series Instruction For Installation And Maintenance

Chapter 1
1 smarttech.com/kb/171257
Chapter 1: Welcome
About this guide 1
Identifying your specific model 2
Identifying your SMARTBoard MX series interactive display model 2
Features 2
Components 3
iQ appliance 4
Screen 4
Pens 5
Front connector panel 5
Front control panel 6
Remote control 6
Remote control sensor 6
Status light 6
Ambient light sensor 6
Internal speakers 6
Accessories 6
SBA-100 projection audio system 7
SMART Audio 400 classroom amplification system 7
USB extenders 7
More information 8
This chapter introduces the SMARTBoard® MX series interactive displays.
About this guide
This guide explains how to install and maintain a SMARTBoard MX series interactive display. It
includes the following information:
l How to install the display
l How to connect power and devices
l How to turn on the display for the first time
l How to configure the iQ appliance

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
