SMART MX Series Instruction For Installation And Maintenance

CHAPTER1
WELCOME
6 smarttech.com/kb/171257
Front control panel
The front control panel contains the Power, Input Select, Menu, Freeze, Mute and volume control
buttons.
Remote control
The remote control is an alternative to the front control panel for controlling the display.
Remote control sensor
The status light blinks green and red when it registers a button being pressed on the remote
control.
Status light
The status light blinks green and red when it registers a button being pressed on the remote
control.
When the status light is red, the display is in a low power state. To wake the display, press the
Power button on the front control panel or POWERon the remote control.
Ambient light sensor
The ambient light sensor can detect the room brightness and adjust the display’s brightness. Make
sure Auto is enabled in Brightness and volume in the display’s settings. See Brightness and volume
on page61.
Internal speakers
The display includes two 10 W rms integrated speakers. You can also connect external speakers
(see Connecting external speakers on page23).
Accessories
Accessories for the display include the following:
l SBA-100 projection audio system
l SMART Audio 400 classroom amplification system
l USB extenders

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
