SMART MX Series Instruction For Installation And Maintenance

CHAPTER7
MAINTAINING THE DISPLAY
41 smarttech.com/kb/171257
Applying the display’s firmware update manually
To apply a system software update
1. A dialog box appears on the screen asking if you want to update the display’s firmware.
2. Tap Update to update the display’s firmware.
OR
Tap Cancel to update the display’s firmware at a later time.
To apply an automatic system software update manually
1.
On the display, press the Menu button on the front control panel.
2. Tap Update.
3. Under Update, tap Update.
Updating system software manually
You can download system software updates at smarttech.com/downloads and update your display
using a USB drive.
1. Go to smarttech.com/downloads and download the update file for your size of display.
2. Copy the .zip file to a USB drive.
3. Insert the USB drive into the display USB.
4.
Press Menu on the front control panel to open the display’s settings.
5. Tap Update.
6. Tap Check.
A dialog box appears.
7. Tap USB.
8. The upgrading software screen appears.
If the update includes an upgrade to the touch firmware, don’t touch the screen during an
update.
9. Using the switch on the back of the display, turn off the display.

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
