SMART MX Series Instruction For Installation And Maintenance

CHAPTER1
WELCOME
4 smarttech.com/kb/171257
No. Name More information
Pictured
1 Screen Page4
2
Front control panel Page6
3 Light sensor Page6
4 Remote control sensor / status light Page6
5
Pen (×2) Page5
6
Speakers Page6
7 Front connector panel
Page5
8
Side connector panel Page25
9
iQ appliance Page4
Not pictured
10 AC switch Page31
11 Bottom connector panel Page26
12 Remote control Page6
iQ appliance
The iQ appliance is inserted in the accessory slot on the back of the SBID-MX265, SBID-MX275
and SBID-MX286 models.
CAUTION
The accessory slot’s maximum available power is 60 W. The slot is not a limited power source.
To reduce the risk of fire, make sure that accessories connecting to the slot satisfy the fire
enclosure requirements of IEC60950-1.
Screen
The following are the dimensions for the display:
Model Diagonal Active touch area Active image area
SBID-MX265 64 1/2" (163.9 cm) 573/8" × 32 3/4" (145.7 cm ×
83.3cm)
56 1/4" × 31 5/8" (142.9 cm × 80.4
cm)

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
