SMART MX Series Instruction For Installation And Maintenance

CHAPTER3
CONNECTING POWER, CABLES AND DEVICES
21 smarttech.com/kb/171257
IMPORTANT
Do not use the RJ45 jack on the iQ appliance to connect to a network.
Connecting cables for room computers,
guestlaptops and other input sources
You can connect cables to the display so that users can connect and use room computers, guest
laptops or other devices, such as Blu-ray™ disc players.
Using recommended cables
SMART recommends the following varieties of cable:
Cable type Maximum length Recommendation
HDMI 23' (7 m)
1
Use only certified HDMI cables that have been
tested to support the performance standard you
require.
VGA 23' (7 m) Use VGA cables with all pins in their connectors fully
populated and wired.
Stereo 3.5 mm 20' (6 m) [N/A]
USB 16' (5 m) Use a USB extender if the distance between the
computer and the display is greater than 16' (5 m).
For more information, see USB extenders on page7.
Using cables that exceed these maximum lengths may produce unexpected results, such as
degraded picture quality or degraded USB connectivity.
1
The performance of cables longer than 23' (7 m) is highly dependent on the cable’s quality.

SMART MX Series Specifications

General

Aspect Ratio	16:9
RAM	4 GB
Internal Storage	32 GB
Refresh Rate	60 Hz
Response Time	8 ms
Brightness	350 cd/m²
Contrast Ratio	4000:1
Dimensions (W x H x D)	Varies by screen size
Weight	Varies by screen size
Screen Sizes	65", 75", 86"
Operating System	Android
Connectivity	HDMI, USB, Wi-Fi, Bluetooth
Audio	Built-in speakers
Touch Points	20
Viewing Angle	178°
VESA Mount	Yes
Display Type	LED-backlit LCD
