SMC Networks EX600 Series User Manual

-113-
No.EX※※-OMX1011
EtherNet/IP
TM
Object
System diagnostic object (Class: 66h)
Instance
Attribute
Access
Name
Type
Value
01h
64h
Get
Input data length
UINT
I/O mapping input data length (Byte)
65h
Output data length
UINT
I/O mapping output data length (Byte)
6Dh
Number of units
connected
USINT
Number of units connected
79h
Get/Set
Hold/Clear
BOOL
0: switch
1: Web Server or EtherNet/IP
TM
object
7Ah
Get
System
Diagnosis 1
BYTE
0: No error, 1: Error
Bit0: The analogue value has fallen below the user set value.
Bit1: The analogue value has exceeded the user set value.
Bit2: The analogue input value has fallen below the set range.
Bit3: The analogue input value has exceeded the set range.
Bit4: The ON/OFF counter has exceeded the set value.
Bit5: The open circuit has been detected.
Bit6: The short circuit of the valve output or digital output
has been detected.
Bit7: The short circuit of the power supply for the
input/output device has been detected.
7Bh
System
Diagnosis 2
BYTE
0: No error, 1: Error
Bit0: The power supply voltage for output device is outside
of the specification.
Bit1: The power supply voltage for control and input is
outside of the specification.
Bit2: Reserved
Bit3: There is a connection failure between each unit
(During operation).
Bit4: There is a connection failure between each unit
(When the power supply is applied).
Bit5: Reserved
Bit6: System error occurred.
Bit7: Hardware error occurred.
9Ch
Unit connecting
condition 1
BYTE
0: No error, 1: Error
Bit0: There is an error in unit 0.
Bit1: There is an error in unit 1.
Bit2: There is an error in unit 2.
Bit3: There is an error in unit 3.
Bit4: There is an error in unit 4.
Bit5: There is an error in unit 5.
Bit6: There is an error in unit 6.
Bit7: There is an error in unit 7.
9Dh
Unit connecting
condition 2
BYTE
0: No error, 1: Error
Bit0: There is an error in unit 8.
Bit1: There is an error in unit 9.
Bit2: Reserved
:
Bit7: Reserved
B0h
Get/Set
Analogue data
endian
BOOL
0: LSB First
1: MSB First
