SMC Networks EX600 Series User Manual

-65-
No.EX※※-OMX1011
•Analogue input unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
The power
supply short
circuit
detection for
the input
device
Generates error
when the short
circuit of the power
supply for the input
device is detected.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
2
Analogue
input range
Sets the analogue
input device range.
-10..10 V
Selects the analogue
input range.
-10..10 V
Channel
-5..5 V
-20..20 mA
0..10 V
0..5 V
1..5 V
0..20 mA
4..20 mA
3
Analogue
data format
Sets analogue data
type which is
output to PLC.
Offset binary
Offset binary.

Unit
Sign &
Magnitude
Signed binary.
2s complement
2’s complement.
4
Analogue
average filter
Sets analogue
filtering time.
None
None
Channel
2AVG
2 value average

4AVG
4 value average
8AVG
8 value average
5
Over range
detection
Generates error
when the input
value exceeds
0.5% of full span.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
6
Under range
detection
Generates error
when the input
value falls below
0.5% of full span.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
7
User setting
value upper
limit error
Generates error
when the input
value exceeds the
set value.
Enable
Generates an error.
1
Channel
Disable
Does not generate an
error.

8
User setting
value lower
limit error
Generates error
when the input
value falls below
the set value.
Enable
Generates an error.
1
Channel
Disable
Does not generate an
error.

1: Set value shall be set per analogue input range within settable range in the table below.
When the analogue input range is changed, check the set value and change it to an appropriate value.
