■Details of diagnostic data
Diagnostic data
Byte
Bit No.
Diagnostic content
0
0
The analogue value has fallen below the user set value.
1
The analogue value has exceeded the user set value.
2
The analogue input value has fallen below the set range.
3
The analogue input value has exceeded the set range.
4
The ON/OFF counter has exceeded the set value.
5
The open circuit has been detected.
6
The short circuit of the valve output or digital output has been detected.
7
The short circuit of the power supply for the input/output device has been detected.
1
0
The power supply voltage for output device is outside of the specification.
1
The power supply voltage for control and input device is outside of the specification.
2
Reserved
3
There is a connection failure between each unit (During operation).
4
There is a connection failure between each unit (When the power supply is applied).
5
Reserved
6
System error occurred.
7
Hardware error occurred.
2
0
There is an error in unit 0.
1
There is an error in unit 1.
2
There is an error in unit 2.
3
There is an error in unit 3.
4
There is an error in unit 4.
5
There is an error in unit 5.
6
There is an error in unit 6.
7
There is an error in unit 7.
3
0
There is an error in unit 8.
1
There is an error in unit 9.
2
Reserved
3
Reserved
4
Reserved
5
Reserved
6
Reserved
7
Reserved
: The data of diagnostic content: "0" means No error and "1" means Error.
