SMC Networks EX600 Series User Manual

-86-
No.EX※※-OMX1011
Diagnosis
By changing the diagnosis switch, the diagnostic data shown below is assigned to the head of input data of
the I/O map. (Refer to "Setting and adjustment (page 19)" for setting the switch.)
Mode
Diagnostic data
Diagnostic size
0
No diagnostic data.
0 byte
1
System diagnosis + Unit diagnosis
4 bytes
