•EtherNet/IP
TM
configuration assembly
The Configuration data per unit type is described below.
Configuration format (EX600-SEN3-X80)
Byte
Bit
EX600-SEN3-X80 (27 byte)
Parameter
Setting value
0
0..3
Unit No.
0..9
4..7
Parameter type
1
1
0..7
Unit ID
9B (Hex)
Unit parameter
2
0
Reserved
0
1
Monitor short circuit (Output)
0: disable, 1: enable
2
Reserved
0
3
Restart after short circuit
0: manual, 1: auto
4
Power supply voltage monitor (Control/Input)
0: disable, 1: enable
5
Power supply voltage monitor (Output)
0: disable, 1: enable
6
Hold /Clear
0: Via switch, 1: Via parameter
7
Reserved
0
Channel parameter – Channel 0 to 7
3
0
(Ch0) Monitor count
0: disable, 1: enable
~
~
~
7
(Ch7) Monitor count
0: disable, 1: enable
4
0
(Ch0) Monitor open circuit
0: disable, 1: enable
~
~
~
7
(Ch7) Monitor open circuit
0: disable, 1: enable
5
0
(Ch0) Output setting during communication fault
0: hold, 1: depend on fault value
~
~
~
7
(Ch7) Output setting during communication fault
0: hold, 1: depend on fault value
6
0
(Ch0) Fault value
0: clear, 1: force ON
~
~
~
7
(Ch7) Fault value
0: clear, 1: force ON
7
0
(Ch0) Output setting during communication idle
0: hold
1: depend on idle value
~
~
~
7
(Ch7) Output setting during communication idle
0: hold
1: depend on idle value
8
0
(Ch0) Idle value
0: clear, 1: force ON
~
~
~
7
(Ch7) Idle value
0: clear, 1: force ON
Channel parameter – Channel 8 to 15
9..14
0..7
See above
See above
Channel parameter – Channel 16 to 23
15..20
0..7
See above
See above
Channel parameter – Channel 24 to 31
21..26
0..7
See above
See above
