Specification
■Specifications
Model
EX600-SEN3-X80
Communication
Protocol
EtherNet/IP
TM
(Conformance version: Composite 11)
Transmission medium
Standard EtherNet cable
(CAT5 or more, 100BASE-TX)
Transmission speed
10 / 100 Mbps
Transmission type
Full duplex / Half duplex
IP address setting range
Setting by SI unit switch: 192.168.0 or 1.1 to 254
Via DHCP server: Arbitrary address
Device information
Vendor ID: 7 (SMC Corporation)
Device type: 12 (Communication Adapter)
Product code: 203
Network topology
Star: Supported
Linear Bus: Supported
Ring (including DLR): Supported
EtherNet/IP QuickConnect
TM
Supported
Web server
Supported
Current consumption
(Power supply for control and inputs)
120 mA or less
Valve output
Output type
Source / PNP (negative common)
Number of solenoid valves
32 outputs
Applicable valve series
Solenoid valve with surge voltage suppressor of 24 VDC and 1.0 W or less
(manufactured by SMC)
Output setting during
communication fault
HOLD / CLEAR / Force ON
Protection
Short circuit protection
Environment
Enclosure
IP67 (manifold assembly)
1
Operating temperature range
-10 to 50
o
C
Storage temperature range
-20 to 60
o
C
Operating humidity range
35 to 85% RH (no dew condition)
Withstand voltage
500 VAC for 1 minute between external terminals and FE
Insulation resistance
500 VDC, 10 MΩ or more between external terminals and FE
Vibration resistance
10 to 57 Hz: constant amplitude 0.75 mm p-p
57 to 150 Hz: constant acceleration 49 m/s
2
for 2 hours in each direction X, Y and Z respectively
(De-energized)
Impact resistance
147 m/s
2
3 times in each directions of X, Y and Z respectively
(De-energized)
Standard
CE marked (EMC directive / RoHS directive), UL (CSA)
Weight
300 g
