I/O Map
Allocated input and output bytes of each unit type
Allocated input and output size is changable according to the diagnosis setting and connected EX600 unit
type. The allocated input and output bytes for each EX600 unit are shown below.
Unit
Unit part number
Allocated bytes
Input
Output
SI unit
EX600-SEN3 / 4
(32 outputs)
0
4
EX600-SEN3 / 4
(32 outputs)
(with diagnostic data)
4
4
Digital input unit
EX600-DX#B
(8 inputs)
1
0
EX600-DX#C
(8 inputs)
1
0
EX600-DX#C1
(8 inputs)
(with open circuit detection)
1
0
EX600-DX#D
(16 inputs)
2
0
EX600-DX#E
(16 inputs)
2
0
EX600-DX#F
(16 inputs)
2
0
Digital output unit
EX600-DY#B
(8 outputs)
0
1
EX600-DY#E
(16 outputs)
0
2
EX600-DY#F
(16 outputs)
0
2
Digital I/O unit
EX600-DM#E
(8 inputs/8 outputs)
1
1
EX600-DM#F
(8 inputs/8 outputs)
1
1
Analogue input Unit
EX600-AXA
(2 channels)
4
(2 bytes per channel)
0
Analogue output Unit
EX600-AYA
(2 channels)
0
4
(2 bytes per channel)
Analogue I/O Unit
EX600-AMB
(2/2 channels)
4
(2 bytes per channel)
4
(2 bytes per channel)
IO-Link master Class A
EX600-LAB1
44
44
IO-Link master Class B
EX600-LBB1
44
44
