SMC Networks EX600 Series User Manual

-98-
No.EX※※-OMX1011
Configuration format (EX600-DY#B)
Byte
Bit
EX600-DY#B (9 byte)
Parameter
Setting value
0
0..3
Unit No.
0..8
4..7
Parameter type
1
1
0..7
Unit ID
08 (Hex)
Unit parameter
2
0
Reserved
0
1
Monitor short circuit (out)
0: disable, 1: enable
2
Reserved
0
3
Restart after short circuit
0: manual, 1: auto
4..7
Reserved
0
Channel parameter – Channel 0 to 7
3
0
(Ch0 output) Monitor counter
0: disable, 1: enable
~
~
~
7
(Ch7 output) Monitor counter
0: disable, 1: enable
4
0
(Ch0 output) Monitor open circuit
0: disable, 1: enable
~
~
~
7
(Ch7 output) Monitor open circuit
0: disable, 1: enable
5
0
(Ch0 output)
Output setting during communication Fault
0: hold
1: depend on fault value
~
~
~
7
(Ch7 output)
Output setting during communication Fault
0: hold
1: depend on fault value
6
0
(Ch0 output) Fault value
0: clear, 1: ON
~
~
~
7
(Ch7 output) Fault value
0: clear, 1: ON
7
0
(Ch0 output)
Output setting during communication idling
0: hold
1: depend on Idle value
~
~
~
7
(Ch7 output)
Output setting during communication idling
0: hold
1: depend on Idle value
8
0
(Ch0 output) Idle value
0: clear, 1: ON
~
~
~
7
(Ch7 output) Idle value
0: clear, 1: ON
