Unit parameter object (Class: 78h)
Instance
Attribute
Access
Name
Type
Value
01h to
0Ah
1
70h
Get/Set
IO-Link master
•Fault output (IO-Link)
BOOL
0: Clear / PD Out valid
1: Hold
2: Clear/ PD Out invalid
71h
IO-Link master
•Fault output (DO)
BOOL
0: Clear
1: Hold
2: Force ON
72h
IO-Link master
•Idle output (IO-Link)
BOOL
0: Clear / PD Out valid
1: Hold
2: Clear / PD Out invalid
73h
IO-Link master
•Idle output (DO)
BOOL
0: Clear
1: Hold
2: Force ON
74h
IO-Link master
•Byte swap
BOOL
0: direct
1: 16 bit
2: 32 bit
3: all
75h
IO-Link master
•Process data mapping
BOOL
0: 2 / 2 / 2 / 2
1: 4 / 4 / 4 / 4
2: 8 / 8 / 8 / 8
3: 16 / 16 / 2 / 2
4: 32 / 2 / 2 / 2
: Port1 / Port2 / Port3 / Port4 process
data size (I/O byte)
1: The instance number 01h to 0Ah is allocated to the Unit No. from 0 to 9.
