SMC Networks EX600 Series User Manual

-119-
No.EX※※-OMX1011
Channel parameter object (2) (Class: 83h to 8Ah)
Class
Instance
Attribute
Access
Name
Type
Value
83h
01h to
0Ah

１
64h to
83h
2
Get/Set
Output setting at communication
error
•SI
•Digital output, I/O
•Analogue output, I/O
BOOL
0: Disable (Hold)
1: Enable
(Clear or Force ON)
84h
Output setting at communication
error (Digital)
•SI
•Digital output, I/O
BOOL
0: Off (Clear)
1: On (Force ON)
85h
Output setting at communication
error (Analogue)
•Analogue output, I/O
UINT
2 bytes AD value
Refer to "Parameter Setting" for
details.
86h
Output setting at communication
idling
•SI
•Digital output, I/O
•Analogue output, I/O
BOOL
0: Disable (Hold)
1: Enable
(Clear or Force ON)
87h
Output setting value at
communication idling (Digital)
•SI
•Digital output, I/O
BOOL
0: Off (Clear)
1: On (Force ON)
88h
Output setting value at
communication idling (Analogue)
•Analogue output, I/O
UINT
2 bytes AD value
Refer to "Parameter Setting" for
details.
89h
Analogue average filter
•Analogue input, I/O
USINT
0: None
1: 2 value average
2: 4 value average
3: 8 value average
8Ah
Analogue range
•Analogue input, output, I/O
USINT
0: -10…+10 V
(Analogue input unit only)
1: -5…+5 V
(Analogue input unit only)
2: -20…+20 mA
(Analogue input unit only)
3: 0…10 V
4: 0…5 V
5: 1…5 V
6: 0…20 mA
7: 4…20 mA
1: The instance number 01h to 0Ah is allocated to the Unit No. from 0 to 9.
2: The attribute number from 64h to 83h is allocated to the channel No. from 0 to 31.
