(7) When [Unit Name] is selected on the [SYSTEM CONFIGURATION STATUS] screen, the [I/O MONITOR]
screen is displayed.
(EX600-DXD)
Select here when selecting
the channel to be displayed.
ON/OFF information can be
monitored for each channel.
Channels which require diagnostic and
detailed diagnostic information are displayed.
