Specification
■Specifications
Model
EX600-ED2-
EX600-ED3-
EX600-ED4-
EX600-ED5-
Power
Power
connector
PWR IN
M12 (5 pin)
Plug
7/8 inch (5 pin)
Plug
M12 (4-pin)
Plug
M12 (4-pin)
Plug
PWR OUT
-
-
M12 (5-pin)
Socket
M12 (5-pin)
Socket
Power supply
(Control and input)
24 VDC ±10%,
2 A
24 VDC ±10%,
8 A
DC24 V ±10%, 4 A
Power supply (Output)
24 VDC +10/-5%,
2 A
24 VDC +10/-5%,
8 A
DC24 V +10/-5%, 4 A
Environment
Enclosure
IP67 (With manifold assembled)
1
Operating temperature range
-10 to 50
o
C
Storage temperature range
-20 to 60
o
C
Operating humidity range
35 to 85%R.H. (No condensation)
Withstand voltage
500 VAC for 1 minute between external terminals and F.E.
Insulation resistance
500 VDC, 10 M min. between external terminals and F.E.
Standard
CE marked
(EMC directive / RoHS directive),
UL (CSA)
CE marked
(EMC directive / RoHS directive)
Weight
170 g
175 g
170 g
1: All unused connectors must have a seal cap fitted.
