Specification
■Specifications
Model
EX600-LAB1
EX600-LBB1
Port class
Class A
Class B
Transmission speed
COM1 (4.8 kbps)
COM2 (38.4 kbps)
COM3 (230.4 kbps)
Automatically switches depending on the device connected
IO-Link version
Version 1.1
Number of ports
4
Power supply for control and inputs
Max. supply current (between L+
and L-)
0.5 A / connector
(2 A / unit)
0.5 A / connector
(1 A / unit)
Power supply for output
Max. supply current (between P24
and N24)
-
1.6 A / connector
3 A / unit
Digital input
Pin No.
2
4
4
Input polarity
PNP
Protection
Short circuit protection
ON input current
Typ. 2.5 mA
Typ. 5.8 mA
Typ. 5.8 mA
ON voltage
13 V or more
OFF voltage
8 V or less
Digital output
Pin No.
4
Output type
PNP
Max. load current
(C/Q line)
0.25 A / output
(Supplied from the power supply for control / input)
Over current protection
Built-in short circuit prevention
Current consumption
50 mA or less
Operating temperature range
-10 to 50
o
C
Storage temperature range
-20 to 60
o
C
Enclosure
IP67 (manifold assembly)
2
Standard
CE marked (EMC directive / RoHS directive), UL (CSA)
1: All unused connectors must have a seal cap fitted.
