3.4 Mounting
(1) Mounting
Details of the controller.
(2) Grounding
Tighten the bolt with the nut when mounting the ground cable as shown below.
Caution
M4 screws, cable with crimping terminal and serrated washer are prepared by customer.
Ground the controller to reduce noise.
Mounting screw （LECP1□□－□）
（Mounting with two M4 screws）
Mounting
direction
Mounting
direction
Grounding
cable
Controlle
r
M4 screw
Cable with crim
p
in
g
terminal
Se
rr
ated
w
as
h
e
r
