2.2 How to Order
How to order is shown below.
Controller
Actuator
＋
Controller
Caution
Single controllers are also shipped after setting the actuator specification parameters.
Confirm the combination of the controller and the actuator is correct.
ＬＥＨＺ１０ＬＫ２－４ＡＦ－Ｒ１１Ｎ１
ＬＥＣＰ１Ｎ□－□
Parallel in
p
ut / out
p
ut t
yp
e
I/O cable length
Applicable motor
(Enter from the actuator model "LE" to ”stroke”）
Ex: LEHZ10LK2-4AF-R11N1
Enter "LEHZ10LK2-4"
Controller
Actuator Model
Ste
p
data
P
Step motor （servo DC24V）
1 14 points (Programless)
N NPN type
P PNP type
Nil No cable
1 1.5m
3 3m
5 5m
* Power cable length is 1.5m only
Controller
I/O cable length
＊
Actuator type
Applicable actuators
Electric gripper LEH Series
Electric slide table LES Series
Electric actuator / Rod type LEY Series
Electric actuator / Slider type LEF Series
Electric actuator / Rotary type LER Series
Nil
No controller
＊
1N
With programless controller (NPN）
1P
With programless controller（PNP）
Nil No cable
1 1.5m
3 3m
5 5m
* If the actuator is ordered without the controller, the
I/O cable type is not available.
LECP6 series I/O cables cannot be used
due to different specification.
Fill in How to Order referring to How to Order of the catalog
of Actuators.
Please refer to the table below for the applicable actuators.
Ex. ：LEHZ10LK2-4AF-R11N1
