10. Initial setting value per actuator
10.1 Initial setting value of LEF series
Initial setting value of LEF series
Refer to the table below for the initial setting of the Return to origin, jog and inching.
LEFB LEFS
16,25,32
common
16A 16B 25A 25B 32A 32B
Direction Side of the motor
Speed [mm/s] 60 30
Return to
origin
Acceleration [mm/s
2
] 1000
Speed [mm/s] 48 10 5 12 6 16 8
Jog
Acceleration [mm/s
2
] 1000
Inching Distance [mm] 5 1
Pushing is not available for LEF series. Even if pushing is set on the the 7-segment LED
○
f of the
controller, it becomes positioning.
Refer to the table below for the speed and the acceleration table of the LEFB series.
LEFB16 LEFB25 LEFB32
Speed
[mm/s]
Acceleration
[mm/s
2
]
Speed
[mm/s]
Acceleration
[mm/s
2
]
Speed
[mm/s]
Acceleration
[mm/s
2
]
0 48 200 48 200 48 200
1 60 300 60 300 60 300
2 70 400 70 400 70 400
3 80 500 80 500 80 500
4 100 600 100 600 100 600
5 150 700 200 700 200 700
6 200 800 300 800 300 800
7 300 900 400 900 400 900
8 400 1000 500 1000 500 1000
9 500 1200 600 1200 600 1200
10 600 1400 700 1400 700 1400
11 700 1600 800 1600 800 1600
12 800 1800 900 1800 900 1800
13 900 2000 1000 2000 1000 2000
14 1000 2500 1200 2500 1200 2500
15 1100 3000 1400 3000 1500 3000
