43
Operations Utilities
Figure 5-25 Color Theme Menu
3. Select White Background or Black Background.
4. Press N/X to exit the menu.
Scanner View
Scanner View lets you set how the data displays when you exit and return to the Scanner. Scanner
View options include:
• Text
• PID List
• Graph
• Last Used View
Refer to the MODIS™ Scanner Plug-in User Manual for details
z To select a Scanner View:
1. Select Utilities > Tool Setup > Scanner View.
The Scanner View dialog box displays.
2. Press Y/a to display a drop-down list (Figure 5-26).
Figure 5-26
Sample Scanner View menu
3. Select an option from the dropdown list, the dropdown list closes automatically.
4. Press N/X to close the Scanner View dialog box.
FGA Demo
Activates a demonstration program for the optional Flexible Gas Analyzer (FGA) module. The
program allows you to view simulated test results without connecting to a vehicle.
z To activate the FGA Demo:
1. Select Utilities > Tool Setup > FGA Demo
A check mark now appears on the menu.
2. Navigate to the main menu and select Gases > Graph/Digital.
The demonstration program begins.
