31EN
ISOM DIGIWARE - 546780C - SOCOMEC
TE-90
or
Tighten the jaws on both
sides of the cable by apply
-
ing pressure.
The jaws must be per
-
pendicular to the holding
notches.
60x10mm50x10mm
I
I
21
Do NOT clamp or pull out NON-INSULATED conductors carrying DANGEROUS VOLTAGE which could
cause an electric shock, burn or arc ash.
Ref. IEC 61010-2-032
