6. CONNECTION
6.1. Connecting ISOM Digiware
DISPLAY
ISOM Digiware D-x5
DIRIS Digiware U
L-60, L-60h
VOLTAGE
MEASUREMENT
(OPTIONAL)
INSULATION
MONITORING
DEVICE (IMD)
1
2
3
4
7
7
8
5 6
ETHERNET
1
Power
supply
24VDC
2
COM
RS485
Modbus
3
U
300 Vac
ph/n
4
1x I/O
input
PTC
120°C
(ref: 4729
0560)
5
4x I/O
24 VDC
/ 40 mA
max
6
U/PE
inputs
L-60:
0-480
VAC/VDC
Ph/Ph
6
U/PE
inputs
L-60h:
0-250
VAC/VDC
Ph/Ph
7
2x alarm
outputs
250Vac
or 30Vdc,
3Amax
8
FE input
9
1x digital
output
ON/OFF
24 VDC -
1A max
x
}
0.2 - 2.5
mm
2
x= 7 mm
0.14 - 1.5
mm
2
x= 7 mm
0.2 - 2.5
mm
2
x= 7 mm
0.2 - 1.5
mm
2
x= 10 mm
0.2 - 1.5
mm
2
x= 10 mm
0.2
- 2.5 mm
2
x= 10 mm
0.2
- 2.5
mm
2
x= 10 mm
0.2
- 2.5
mm
2
x= 10 mm
0.14 - 1.5
mm
2
x= 7 mm
(1)
Earth must not be used in a neutral IT system
