Module FLD
ISOM Digiware F-60 0.5
Single-point alert report
ISOM D-15h 0.5
Repeater
DIRIS Digiware C-32 1.5
Single-point display
ISOM T-15 0.05
(*) Max 20 W for use by the Digiware system
7.2.2. Calculation rules for the max. number of products on the Digiware bus
The total power consumed by the equipment connected to the Digiware bus must not exceed the power from the
24 VDC power supply.
Size with P15 power supply (ref: (4829 0120) delivering 15 W
You can use the following, for example:
• 1 ISOM Digiware D-75 (2.5 W) display
• 1 IMD ISOM Digiware L-60 (2.3W) module
• 25 metres of cable (0.75 W)
and
• 2 FLD ISOM Digiware F-60 (1 x 0.5 = 5.5 W) modules
• 6 ISOM T-15 adapters (66 x 0.05 = 3.3 W)
g Total power = 14.35 W
Dimensioning with a P30 power supply (ref. 4729 0603) delivering a maximum usable power of 20 W by
the Digiware system
You can use the following, for example
• 1 ISOM Digiware D-75 (2.5 W) display
• 1 ISOM Digiware L-60 IMD module (2.3 W)
• 1 DIRIS Digiware voltage module U-xx (0.72 W)
• 25 metres of cable (0.75 W)
and
• 17 FLD ISOM Digiware F-60 (17 x 0.5 = 8.5 W) modules
• 102 ISOM T-15 adapters (102 x 0.05 = 5.1 W)
g Total power = 19.87 W
