socomec ISOM Digiware - TE Sensor Bar Mounting

30 EN
ISOM DIGIWARE - 546780C - SOCOMEC
TE-90
2
1
Removing clamps
I
NB: Use the clamps to install the TE-90 sensors on a cable with clamping collar.
Do NOT clamp or pull out NON-INSULATED conductors carrying DANGEROUS VOLTAGE which could
cause an electric shock, burn or arc ash.
Ref. IEC 61010-2-032
5.3.5. Bar mounting
TE-35 - > TE-55
A
A A
C
B
Installation options:
A+B, A+C
0.4Nm, 4mm
key
B
C
