SolarEdge Auto-Transformer Technical Specifications
SEAUTO-TX-5000
ELECTRICAL RATINGS
Rated Power - Continuous 5000 VA
Rated Power - Peak 7600 for 10 sec VA
Output Voltage 120/ 240 Split Phase V
Max Continuous Output Current per Phase @120V 25 A
Split Phase Imbalance (@ Rated Power) Up to 25A difference between phases
Thermal Protection Yes
INSTALLATION SPECIFICATIONS
AC Output conduit size / AWG range 0.75 / 14-10 in/ AWG
Dimensions (HxWxD) 6.7 x 7.9 x 5.5 / 170 x 200 x 140 in / mm
Weight 29.7 / 13.5 lb / kg
Min - Max Operating Temperature -13 to +140 / -25 to +60 °F / °C
Protection Rating NEMA 3R
Installation Wall mounted
Auto-Transformer Technical Specifications MAN-01-00372-1.0
1
