SolarEdge StorEdge SE7600A-USS

Step 1: Activating the System
1. VerifythattheinverterON/OFFswitchisOFF.
2. MovetheStorEdgeConnectionUnitON/OFFswitchtotheOFFposition.
3.
Removetheinvertercover:Opentheinvertercover’ssixAllenscrewsandcarefullypullthecover
horizontallybeforeloweringit.
WARNING!
ELECTRICAL SHOCK HAZARD. Do not touch uninsulated wires when the inverter cover is
removed.
RISQUE D’ÉLECTROCUTION, ne touchez pas les fils non isolés lorsque le couvercle de
l'onduleur est retiré.
4.
Activatetheinverter:
a. VerifythatthecardS/NmatchestheinverterS/N.
b. Insertthecardintothe"CARD"slotonthecommunicationboard.
c. TurnONtheACswitchofthemaincircuitboard.
d. LCDshows:Running Script...è Done!
Figure 27: Activation card
IfLCDshows:Failed:
l TurnACOFFandON(reset),andrepeattheactivationprocess.
l Usetheactivationcodethatappearsonthecertificationinverterlabeltomanuallyactivatethe
inverter.
l Iftheproblempersists,contactSolarEdgeSupport.
NOTE
Youcanusetheactivationcodethatappearsonthecertificationinverterlabelto
activatetheinverterincaseofascripterrororamissingactivationcard.

