To access the Energy Ctrl menu:
1.
EnterSetupmode,scrolldowntothe Power Control menuandselectit.Amenusimilartothe
followingisdisplayed:
G r i d C o n t r o l < E n >
E n e r g y M a n a g e r
R R C R C o n f .
R e a c t i v e P w r C o n f .
A c t i v e P w r C o n f .
P h a s e B a l a n c e < D i s >
W a k e u p C o n f .
P ( f )
A d v a n c e d
L o a d D e f a u l t s
2.
SelectEnergy Manager.Thefollowingscreenisdisplayed:
L i m i t C o n t r o l < D i s >
E n e r g y C t r l < D i s >
S t o r a g e C t r l
A d v a n c e d
Limit Control:Forpowerlimitation(includingexportlimitation)configuration.Thisoptioncanbe
usedinparalleltoenergycontrol.Formoreinformationreferto
http://www.solaredge.us/files/pdfs/products/export_limitation_application_note_NA.pdf.

o
E:Exportlimit

o
P:Productionlimit

o
Dis:Disabled-nolimit
Energy Control:Themethodbywhichtomanagetheenergy.
Storage Control:Enablesreservingaminimumbatterychargelevel.
3.
SelectEnergy Ctrl..Thefollowingisdisplayed,showingtheSolarEdgeapplications:
M a x S e l f - c o n s u m e
T i m e o f U s e
B a c k u p O n l y
D i s a b l e
Max Self-consume (MSC):MaximizeSelf-consumption
Time of Use(TOU):Charge/DischargeProfileProgramming
Backup Only:Supplypowertoloadsduringpoweroutage
Disable:Noenergycontrol,thatis,thebatteryisnotused
Setting Backup-Only
WhentheinverterissettoBackup-onlymode,thebatterywilldischargetosupplypowertothebacked-
uploadsonlyuponpoweroutage.
To set up Backup-only:
1. AccesstheEnergy Ctrlmenuasdescribedabove.
