SolarEdge StorEdge SE7600A-USS User Manual

Installation Equipment List
StandardtoolscanbeusedduringtheinstallationoftheSolarEdgesystem.Thefollowingisa
recommendationoftheequipmentneededforinstallation:
l Allenscrewdriverfor5mmscrewtypefortheinvertercover,StorEdgeConnectionUnitcover,and
invertersidescrews
l Standardflat-headscrewdriversset
l Non-contactvoltagedetector
l Cordlessdrillorscrewdriverandbitssuitableforthesurfaceonwhichtheinverterwillbeinstalledand
foropeningtheStorEdgeConnectionUnitknockouts
l Suitablehardwareforattachingtheinvertermountingbrackettothesurfacetowhichitwillbe
connected
l 1/4"or5/16”stainlessbolts,nuts,andwashersforattachingthepoweroptimizertotheracking(not
requiredforsmartmodules)
l Wirecutters
l Wirestrippers
l Voltmeter
Forinstallingthecommunicationoptions,youmayalsoneedthefollowing:
l ForEthernet:

o
CAT5/6twistedpairEthernetcablewithRJ45connector.

o
IfusingaCAT5/6cablespool:RJ45plugandRJ45crimper
l ForRS485:

o
Four-orsix-wireshieldedtwistedpaircable.

o
Watchmakerprecisionscrewdriverset
Inverter Transport and Storage
Transporttheinverterinitsoriginalpackaging,facingupandwithoutexposingittounnecessaryshocks.
Iftheoriginalpackageisnolongeravailable,useasimilarboxthatcanwithstandtheweightofthe
inverter(refertotheinverterweightinthespecificationdatasheetprovidedwiththeunit),hasahandle
systemandcanbeclosedfully.
Storetheinverterinadryplacewhereambienttemperaturesare-13°F-140°F/-25°C-+60°C.
SolarEdge StorEdge Installation Guide MAN-01-000262-1.2
12
