l Module:Poweroptimizerserialnumber
l Energy:poweroptimizerenergy
l Vdc_O:Poweroptimizeroutputvoltage
l Vdc_I:Poweroptimizerinputvoltage(modulevoltage)
l I_in:Poweroptimizerinputcurrent
l Temp:Poweroptimizertemperature
ID Status
Thisscreendisplaystheinvertersoftwareversionandthecountrytowhichtheinverterisconfigured.
D S P 1 / 2 : 1 . 0 2 1 0 / 1 . 0 0 3 4
C P U : 0 0 0 3 . 1 9 x x
C o u n t r y : U S A 1
l ID:TheinverterID.
l DSP 1/2:TheDSPdigitalcontrolboardfirmwareversion
l CPU:Thecommunicationboardfirmwareversion
l Country:thecurrentcountrysetting
Server Communication Status
S e r v e r : L A N < S _ O K >
S t a t u s : < O K >
x x x x x x x x
< E R R O R M E S S A G E >
NOTE
If the connection method is CDMA (Cellular) or GSM, the server screen is replaced with the Cellular or
GSM status screens (see Cellular Status on the facing page and GSM Status on the facing page).
l Server:ThemethodofconnectiontotheSolarEdgemonitoringplatform.
l S_OK:TheconnectiontotheSolarEdgemonitoringplatformissuccessful(shouldappearonlyiftheis
connectedtotheserver).
l Status:DisplaysOKiftheinverterestablishedsuccessfulconnectionandcommunicationwiththe
specifiedserverport/(LAN,RS485orZigBeecard).
l xxxxxxxx:Eight-bitEthernetcommunicationconnectionstatus:Astringof1sand0sisdisplayed.1
indicatesOK,0indicatesanerror.Foralistofthepossibleerrorsandhowtotroubleshootthem,refer
toCommunicationTroubleshootingonpage87.
l Error message,accordingtofailure.RefertoTroubleshootingonpage87.
IP Status
ThisscreendescribestheEthernetconfiguration:IP,Mask,GatewayandMACaddress(MediaAccess
Control)oftheInverter.
I P 1 9 2 . 1 6 8 . 2 . 1 1 9
M S K 2 5 5 . 2 5 5 . 2 5 5 . 0
G W 1 9 2 . 1 6 8 . 2 . 1
M A C 0 - 2 7 - 0 2 - 0 0 - 3 9 - 3 6
SolarEdge StorEdge Installation Guide MAN-01-000262-1.2
64
ID Status
