SON PXW-FX9V - Tools and Fixtures; Circuit Protection Parts; Electrical Adjustment

24
1-6-3. UIF-16 Board
Ref No.
Name
Color
Description
Normal State
(Power On)
D2001
JKZ9
Orange
For checking IC2002 (CPLD) operation
This LED blinks when IC2002 operates normally.
Blinks
D2002
Done
Yellow green
Indicates completion of IC2002 (CPLD) configuration.
After configuration is completed, this LED lights when
the grip is connected to the camera body.
On
UIF-16 Board/Side A
D2001
D2002
