2-4-1. Lithium Battery
Preparation
1. Remove the bottom harness guard. (Refer to “2-2. Bottom Harness Guard”.)
2. Remove the outside panel assembly. (Refer to “2-3. Outside Panel Assembly”.)
3. Remove the inside panel assembly. (Refer to “2-4. Inside Panel Assembly”.)
Procedure
1. Remove the lithium battery with a non-conductive stick.
2. Install the removed parts by reversing the steps of removal.
KSW-72 board
Hooks
Hooks
Lithium battery
Battery holder
Groove
