SON PXW-FX9V - Overall-2

95
Overall-2
No. Part No. SP Description
101 A-5012-205-A s ASSY, SHOULDER PAD
102 X-5000-836-1 s ASSY, BOTTOM PLATE
103 2-630-005-31 s SCREW(M2),NEW TRUSTER,P2
104 4-587-420-01 s LID, BM
105 4-684-602-01 s RING (956), ROSSETTE
106 5-008-498-01 s PLATE, ROSETTE RING
107 5-008-649-01 s CABINET, BOTTOM
108 5-008-653-01 s GUARD, BOTTOM HARNESS
109 5-008-702-01 s CLAMPER, UM CABLE
110 5-008-757-01 s PAD, SHOULDER
111 5-008-759-01 s TRIPOD
7-623-923-01 s WASHER 2.6, NYLON
7-683-404-04 s BOLT,HEXAGON SOCKET 3X8
7-683-412-05 s BOLT,HEXAGON SOCKET 2.6X6
7-688-003-12 s W 3, MIDDLE
W3
W2.6
W3
W3
W3
HEXAGON SOCKET
BOLT 2.6 x 6
HEXAGON SOCKET
BOLT 2.6 x 6
HEXAGON SOCKET
BOLT 3 x 8
W3
W3
W2.6
W2.6
106
103
103
108
102
103
107
111
103
104
101
110
105
103
109
103
103
