SON PXW-FX9V - Bottom Harness Guard

35
2-2. Bottom Harness Guard
Procedure
1. Remove the four precision screws, and then remove the front cover.
2. Remove the two precision screws, and then remove the BOB lid assembly in the direction of the arrow.
Precision screws
(P2 x 4)
Front cover
Precision screws
(P2 x 4)
BOB lid assembly
Hook
