Section 4
Service Menu
4-1. Overview
The unit is provided with the Service menu that is useful for maintenance and adjustment. The menu content is displayed on the
viewfinder.
The Service menu consists of the following menus.
Menu Item
Description
Auto Black Balance
Auto black balance adjustment
RPN
Auto/manual RPN registration, deletion, and automatic detection
Factory Reset
Resets all settings of the unit to the factory default.
Information
Information and status of the unit display
Version
Information and status of the unit display
4-2. Displaying the Service Menu
1. Press the MENU button to display the setup menu.
2. Select [Hours Meter] of the [System].
3. Hold down both the SET button and the Assign1 button, and press the MENU button.
Service menu is displayed.
Tip
To exit the service menu, turn off and on the unit.
4-3. Service Menu List
Menu Item
Submenu Item
Choice
Function
Reflection of setting
Auto Black Balance
Auto Black Balance
Execute / Cancel
Executes the auto black balance.
Starts after “Execute” is
selected
RPN
APR
Execute / Cancel
Executes the automatic defect
correction function (automatic pixel
noise reduction)
Starts after “Execute” is
selected
Reset
Execute / Cancel
Deletes all the concealment targets
registered by APR.
Starts after “Execute” is
selected
Factory Reset
Reset
Execute / Cancel
Executes the factory reset.
Select “Execute” from the
execution instruction wait
message displayed after
“Execute” is selected
Information
Serial Number
Seven digit number
Displays the serial number.
(Only displayed)
Imager Temperature
XX °C
Displays the internal temperature
(Only displayed)
Main Board Temperature
XX °C
Displays the internal temperature
(Only displayed)
Ext. Unit Temperature
XX °C
Displays the internal temperature
(Only displayed)
Log Dump
Execute / Cancel
Manually dumps the unit log.
Starts after “Execute” is
selected
Version
Package
-
Displays the package version.
x.xx_xxxx (Only displayed)
