Section 3
Error Code
If a problem occurs during operation of the unit, an error code will appear in the view finder display.
Check the details of the error code and respond accordingly.
3-1. Error Code List
Error
code
Description Check and Action
E12-001 CMR failure
Check: ND unit, IC6501 (CR-53 board), IC2001 (DPR-394 board), and the peripheral
devices.
Repair or replace: DPR-394 board, CR-53 board, ND unit.
E12-002
Abnormal temperature due to
disconnection or short-circuit of the
thermistor for CMR
Check: ND unit, IC6501 (CR-53 board), IC2001 (DPR-394 board), and the peripheral
devices.
Repair or replace: DPR-394 board, CR-53 board, ND unit.
E12-003 Electric insertion or removal error of CMR
Check: ND unit, IC6501 (CR-53 board), IC2001 (DPR-394 board), and the peripheral
devices.
Repair or replace: DPR-394 board, CR-53 board, ND unit.
E12-004 CMR position detection PI error
Check: ND unit, IC6501 (CR-53 board), IC2001 (DPR-394 board), and the peripheral
devices.
Repair or replace: DPR-394 board, CR-53 board, ND unit.
E91-119
Communication error from IC6000
(DPR-394 board) to IC7708 (DPR-394
board)
Check: IC6000, IC7708 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-11C
Communication error from IC6000
(DPR-394 board) to IC7704 (DPR-394
board)
Check: IC6000, IC7704 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-133 Verification error
Check: IC6000, IC2001 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-145
Communication error from IC6000
(DPR-394 board) to IC3002 (DD-55
board)
Check: IC6000 (DPR-394 board), IC3002 (DD-55 board), and the peripheral devices.
Repair or replace: DD-55 board, DPR-394 board.
E91-185
Communication error from IC6000
(DPR-394 board) to IC302 (VIO-38
board)
Check: IC6000 (DPR-394 board), IC302 (VIO-38 board), and the peripheral devices.
Repair or replace: VIO-38 board, DPR-394 board.
E91-1C0
Communication error from IC6000
(DPR-394 board) to WiFi module
Check: IC6000 (DPR-394 board), CP7330 (CT-289 board), WiFi antenna (WF-12
board), and the peripheral devices.
Repair or replace: WF-12 board, CT-289 board, DPR-394 board.
E91-1D0
Communication error from IC6000
(DPR-394 board) to GPS module
Check: IC6000 (DPR-394 board), GPS module (GP-1019 board), and the peripheral
devices.
Check whether the handle is properly connected to the unit. If the problem persists,
repair or replace the GP-1019 board and the DPR-394 board.
E91-1F0
Communication error from IC6000
(DPR-394 board) to SE7602 (DPR-394
board)
Check: IC6000, SE7602 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-250
Communication error from IC6000
(DPR-394 board) to IC3001 (DPR-394
board)
Check: IC6000, IC3001 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-270
Communication error from IC6000
(DPR-394 board) to IC4801 (DPR-394
board)
Check: IC6000, IC4801 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-338
Memory failure in IC2001 (DPR-394
board)
Check: IC2001 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-33D RTC device failure
Check: IC2001, IC7709 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
