SON PXW-FX9V - Description of SERVICE Menu

89
Error
code
Description Check and Action
E91-36C
Temperature sensor alarm in the
XDCA-FX9
Check: IC0603 (HIF-80 board) in the XDCA-FX9, and the peripheral devices.
Repair or replace: HIF-80 board.
E91-350
Communication error from IC2001
(DPR-394 board) to IC3501 (DPR-394
board)
Check: IC2001, IC3501 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-357
Memory failure in IC3501 (DPR-394
board)
Check: IC3501 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-360
Communication error from IC2001
(DPR-394 board) to IC2001 (HIF-80
board) in the XDCA-FX9
Check: IC2001 (DPR-394 board), IC2001 (HIF-80 board) in the XDCA-FX9, and the
peripheral devices.
Repair or replace: HIF-80 board, DPR-394 board.
E91-367
Memory failure in IC2001 (HIF-80 board)
in the XDCA-FX9
Check: IC2001 (HIF-80 board) in the XDCA-FX9, and the peripheral devices.
Repair or replace: HIF-80 board.
E91-370
Communication error from IC2001
(DPR-394 board) to IC0700 (DIF-278
board)
Check: IC2001 (DPR-394 board), IC0700 (DIF-278 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-377
Memory failure in IC0700 (DIF-278
board)
Check: IC0700 (DIF-278 board), and the peripheral devices.
Repair or replace: DIF-278 board.
E91-380
Communication error between IC2001
(DPR-394 board) and IC8402 (KSW-72
board)
Check: IC2001 (DPR-394 board), IC8402 (KSW-72 board), and the peripheral
devices.
Repair or replace: KSW-72 board, DPR-394 board, or the harness between these
boards
E91-390
Communication error from IC2001
(DPR-394 board) to IC3701 (DPR-394
board)
Check: IC2001, IC3701 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-3C0
Communication error between IC2001
(DPR-394 board) and IC6004 (SDI-127
board)
Check: IC2001 (DPR-394 board), IC6004 (SDI-127 board), and the peripheral devices.
Repair or replace: SDI-127 board, DPR-394 board, or the harness between these
boards
E91-3D0
Communication error between IC2001
(DPR-394 board) and SE7731 (DPR-394
board)
Check: IC2001, SE7731 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E91-623
Communication failure between IC6501
(CR-53 board) and IC2001 (DPR-394
board)
Check: ND unit, IC6501 (CR-53 board), IC2001 (DPR-394 board), and the peripheral
devices.
Repair or replace: DPR-394 board, CR-53 board, ND unit.
E91-627
Failure in downloading program of
IC2001 (DPR-394 board) to IC6501
(CR-53 board)
Check: ND unit, IC6501 (CR-53 board), IC2001 (DPR-394 board), and the peripheral
devices.
Repair or replace: DPR-394 board, CR-53 board, ND unit.
E92-303
Communication error from IC2001
(DPR-394 board) to IC7001 (DPR-394
board)
Check: IC2001, IC7001 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E95-205 Internal error of IC3001 (DPR-394 board)
Check: IC3001 (DPR-394 board), and the peripheral devices.
Repair or replace:
DPR-394 board.
E95-206 Internal error of IC3001 (DPR-394 board)
Check: IC3001 (DPR-394 board), and the peripheral devices.
Repair or replace:
DPR-394 board.
E95-207 Internal error of IC3001 (DPR-394 board)
Check: IC3001 (DPR-394 board), and the peripheral devices.
Repair or replace:
DPR-394 board.
E95-125 Recording stopped
Check: IC2001, IC6000 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E95-232
Communication error from IC0700
(DIF-278 board) to IC6000 (DPR-394
board)
Check: IC0700 (DIF-278 board), IC6000 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board, DIF-278 board.
E95-312
Communication error from IC1001
(DPR-394 board) to IC2001 (DPR-394
board)
Check: IC1001, IC2001 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
E95-314
Communication error from IC3001
(DPR-394 board) to IC2001 (DPR-394
board)
Check: IC2001, IC3001 (DPR-394 board), and the peripheral devices.
Repair or replace: DPR-394 board.
Continued
