55
4. Remove the VSW-82 board.
5. Disconnect the flexible flat cable from the connector (CN001) on the VSW-82 board.
Note
At the time of the installation, align the switches with the levers.
6. Install the removed parts by reversing the steps of removal.
VSW-82 board
Flexible flat cable
Levers
Switches
CN001
