SON PXW-FX9V - DPR-394 Board

60
4. Open the HDMI lid, and then remove the two precision screws (P1.7 x 5).
5. Remove the two precision screws (P2 x 4), and then remove the terminal assembly in the direction of the arrow.
6. Install the removed parts by reversing the steps of removal.
Precision screws
(P2 x 4)
Precision screws
(P1.7 x 5)
HDMI lid
Terminal assembly
