SON PXW-FX9V - IF-1377 Board, DIF-278 Board

72
4. Disconnect the fine-wire coaxial cable from the connector (CN901) on the EC-94 board.
5. Remove the two gasket P (389) and the two media graphite cushions.
6. Install the removed parts by reversing the steps of removal.
Fine-wire coaxial cable
EC-94 board
CN901
Media graphite cushions
Gasket P (389)
Gasket P (389)
