22 Chapter 4: Setup and Operation
7 Near Adjusts the gain applied to the near field of the image.
Far Adjusts the gain applied to the far field of the image.
Gain Adjusts the overall gain applied to the entire image.
8 AC power
indicator
A steady green light indicates AC power is connected. A flashing green light
indicates the system is in sleep mode.
9 Caliper/Calcs Caliper activates a measurement caliper on the screen.
Calcs turns the calculation menu on and off.
10 Touchpad Use to select, adjust, and move objects on the screen.
11 Select Use to switch between frozen images in duplex and dual screens. color and
Doppler menus, calipers for measurement (calipers), pictograph marker
position/angle (picto), arrow position/orientation (arrow).
12 Print Prints the active image to the printer.
13 Save Saves an image to the CompactFlash card.
Saves an image to the CompactFlash card and saves measurements/calculation
to the report when configured in system setup.
14 Remappable
controls
Controls features on the context menu which are adjusted based on the system
state.
15
Forms
Setup Access to the system settings.
Report Access to the patient report.
Review Access to the patient list and saved patient images, and archive functions.
Patient Access to patient information.
16
(Delta key)
Use as a shortcut to existing functionality in the system.
17 Save clip Saves a clip to the CompactFlash card.
Record Turns DVD/VCR record on and off.
18 Freeze Stops the live imaging and displays a frozen image.
Cine
(back/forward)
Review images stored in the cine buffer; back/forward through last-in, first-out
sequence. All mode images can be stored and reviewed in the cine buffer.
19 Update Toggles between dual and duplex screens and image modes in M Mode and
Doppler, e.g., between 2D Doppler sample line and Doppler spectral trace.
Table 4.1: System Controls (Continued)
Number System Control Description
