SonoSite MicroMaxx - Control Panel Subassembly Replacement

62 Chapter 7: Replacement Procedures
Test the Display
Control Panel Subassembly Replacement
Required Parts
• P05462 Service Assembly, Control Panel MicroMaxx, English or
• P05464 Service Assembly, Control Panel MicroMaxx, English, International, or
• P05465 Service Assembly, Control Panel MicroMaxx, French, or
• P05466 Service Assembly, Control Panel MicroMaxx, German, or
• P05467 Service Assembly, Control Panel MicroMaxx, Italian, or
• P05468 Service Assembly, Control Panel MicroMaxx, Spanish, or
• P05469 Service Assembly, Control Panel MicroMaxx, Portuguese
Required Tools
• #1 Phillips screwdriver
• Torque screwdriver, 2.0–10.0 inch pounds (0.23–1.1 newton meter)
•8mm nut driver
• An anti-static mat
• A wrist grounding strap
Control Panel Removal
Control Panel Replacement
Test Display 1 Replace the battery, attach an external power supply, or attach a mini-dock.
2 Press the Power key to apply power to the system.
3 Verify the display operates correctly.
Caution:
Always use correct ESD procedures. ESD damage is cumulative and may not be noticeable at first.
Initial ESD symptoms may be slightly degraded performance or image quality.
Control Panel
Removal
1 Remove the two screws from the rear of the system per Figure 7.1.
2 Remove the two screws from the bottom of the system per Figure 7.2.
3 Turn the system over, fully open the display, and lift off the Control Panel per Figure 7.3.
Control Panel
Replacement
1 Place the new control panel in place.
2 Install the four screws removed in Section . Torque the screws to 5.5 inch pounds.
