Chapter 8: Performance Testing 73
Pulsed Wave (PW) Doppler Imaging
Image Quality Verification Test/Livescan
• Products with replaced subassemblies, or products that have been otherwise disassembled, must undergo an
Image Quality Verification Test/Livescan.
• The Image Quality Verification Test/Livescan should be performed after successfully completing Section ,
“Setting Up Performance Tests,” on page 69 and Section , “CPD,” on page 72.
• The test is completed before returning the system to service.
• A certified sonographer must perform the test.
• The Livescan test performed is at the discretion of the Sonographer and will represent their acceptance of a
successful service event.
Image Review
Review all saved images and verify that the images are displayed properly.
Printer
Battery Charging
Test PW
Doppler
Imaging
1 Attach the C15 transducer.
2 Press the Doppler key for the Doppler sample gate.
3 Press the Doppler key again for the Doppler spectral trace.
4 Place a large drop of ultrasound gel on the transducer lens.
5 Gently tap the top of the gel and observe a reflection on the spectral trace and the sound
from the speakers.
6 Press the 2D key to return to 2D imaging.
Test Printer
Operation
1 Print two images in rapid succession and verify proper operation.
2 Verify that the print control on the system functions correctly.
Test Battery
Charging
Operation
1 Remove the system from the Docking System and insert a battery into the system.
2 Press the Power key to turn the system on. Allow the battery to discharge. The battery
indicator icon on the display, below the Transducer Type indicator, will extinguish from left
to right as the battery discharges.
Note: The battery may take 1–2 hours to discharge.
3 Reattach the system to the Docking System and attach the AC power cord to the power
connector.
4 Note that the battery indicator indicates that the battery is charging. The sections of the
battery indicator will light sequentially from left to right as the battery charges.
5 If charging is not evident, see Chapter 6, “Troubleshooting” for troubleshooting procedures.
