Working Instructions (mech)
1225-1010 Rev 1
Disassembly
Do the same with the second hook.
Turn the SIM Flex/Carrier Unit over,
and use the Front Opening Tool to disconnect the BtB
connector.
Remove the SIM Flex/Carrier Unit.
© Sony Ericsson Mobile Communications AB – Company Internal
12(70)
