Working Instructions (mech)
1225-1010 Rev 1
Disassembly
Carefully insert the dentist hook underneath one of the two
Screw Sheets and remove it.
Scrap! Not to be reused!
Do the same with the second Screw Sheet.
3.8 Front Cover
Remove the two 1.6 mm black screws by using the JCIS bit.
Close the slider.
© Sony Ericsson Mobile Communications AB – Company Internal
14(70)
